特性 : |
| |
| Operating speed |
0.5mm to 50m/sec |
| Operating frequency |
Mechanically:120 operations/min.
Electrcally:30 operatioms/min. |
| Contact resistance |
15m  max.(initial) |
| Insulation resistance |
100M min,(at 500 VDC) |
| Dielectric strength |
1,000VAC. 50/60 Hz for 1 minute between non-continuous terminals
2,000VAC. 50/60 Hz for 1 minute between each terminal and non-current carrying metal part and between each terminal and ground. |
| Vibration |
Malfunction durability:10 to 55 Hz;
1.5mm double amplitude. |
| Shock |
Mechanical durability:
Approx. 1,000m/sec2 (approx.100G's)
Malfunction durability :
Approx.300m/sec2 (approx.30G's) |
| Ambient temperature |
Operating : -15 to +70 |
| Humidity |
95% RH max |
| Service life |
Mechanically:
10,000,000 operations min
Electrically:
300,000 operations min,(2A,110VAC)MAX. |
| Degree of protection |
IEC 529 class IP65 |
|
| |
|
|
 |
|
