  防油限制開關  (Made in Taiwan)
功能 :
可配合各種不同之連桿及頭
具多種使用特性曲線
接線頭具帽式覆蓋螺絲
防塵、防油、防水
不鏽鋼主零件
規格及尺寸標準化 1/2” conduit entry.
適用溫度 +15°F  to +175°F  (-10℃ to  +80℃)

所有密封式限制開關都是雙迴路限制開關,1NO(常開)與1NC(常閉 )迴路,各迴路接點俱為兩段式絕緣。

額定電壓 :

10A

125 or 300V AC(resistive)

0.8A

125 VDC(resistive)

0.4A

250V DC

1/2HP

125 V AC

1HP

250 V AC


電氣迴路 :


特性 :

Operating speed

1mm to 2m/sec

Operating frequency

Mechanically: 120 operations/min.
Electrically: 30 operations/min.

Contact resistance

15m max.(initial)

Insulation resistance

100M min.(at 500 VDC)

Dielectric strength

1,000 VAC, 50/60 Hz for 1 minute between non-continuous terminals
2,200 VAC, 50/60 Hz for 1 minute between each terminal and non-current-Carrying metal part and between each terminal ground.

Vibration

Malfunction durability:10 to 55Hz 1.5mm double amplitude

Shock

Mechanical durability:
Approx.1,000m/sec2 (approx. 100G's)
Malfunction durability:Approx.300m/sec2 (approx.30 G's)

Ambient operating temperature

Operating:-10 to +80

Humidity

95% RH max

Service life

Mechanically:
15,000,000 operations min
Electrically:(2.5A, 110VAC)MAX
500,000 operations min.

Degree of protection

IEC 529 class IP65
(Sealed accessories requirement)
