	M8 SERIES Positive Opening Limilt Switches  (Made in Taiwan)
	Technical data: General Standards IEC/EN 60947 Climatic proofing Damp heat, constant,, to IEC 60068-2-78 Damp heat, cyclic. to IEC 60068-2-30 Ambient temperature -25 / +70 Mounting position As required Degree of protection IP66. IP65 for "T" Type with rubber strain Contacts/switching capacity Rated impulse withstand voltage Uimp VAC 4000 Rated insulation voltage Ui V 400 Overvolatge category/pollution degree III/3 Rated operational current AC-15 24V Ie A 6 230V/240V Ie A 6 400V/415V Ie A 4 DC-13 24V Ie A 10 110V Ie A 1 220V Ie A 0.5 Control circuit reliability at 24V DC / 5mA HF Fault probability <10-7,<1 failure at 107 operations at 5V DC / 1mA HF Fault probability <10-6,<1 failure at 5x106 operations Supply frequency Hz max. 400 Short-circuit rating in the closed state (IEC / EN 60947-5-1) Fuseless Type PKZM0-10 FAZ-B6/1 Max. Fuseless A gG / gL 10 Short-circuit rating to IEC / EN 60947-5-1 Max. Fuseless A gG / gL 6 Repetition accuracy mm 0.02
